2020-2021 Chevy/GMC 2500HD 5in Suspension System W/O Overload Suspension System
Take your GM 2500/3500HD to new heights with this 5" lift kit from Zone Offroad. Kits include everything needed from high strength crossmembers and steering knuckles to differential relocation and and rear block kit to level out the stance. Get the look, performance, and capability your truck deserves with clearance for up to 37" tires.
Take your GM 2500/3500HD to new heights with this 5" lift kit from Zone Offroad. Kits include everything needed from high strength crossmembers and steering knuckles to differential relocation and and rear block kit to level out the stance. Get the look, performance, and capability your truck deserves with clearance for up to 37" tires.
- Maintains ride quality and handling characteristics
- Improves ground clearance while correcting suspension-steering-driveline geometry
- High strength 1/4" thick steel crossmembers and differential skid plates
- CNC machined ductile iron steering knuckles to maintain ESC System compatibility
- Zone Offroad branded front skidplate and torsion bar relocation brackets
- Allows clearance for up to 37" tires to be installed
Application Summary:
| Year | Make/Model |
|---|---|
| 2020-2024 | Chevrolet Silverado 2500 HD |
| 2020-2024 | Chevrolet Silverado 3500 HD |
| 2020-2024 | GMC Sierra 2500 HD |
| 2020-2024 | GMC Sierra 3500 HD |
This item is a package with the following components:
| Attributes | |
| Accommodates Factory Wheels | See Notes |
| Adjustable | No |
| Alternate Part Number | ZONC43F |
| Back Spacing | 5-5.5" |
| Back Spacing 2 | 5-5.5" |
| Back Spacing 3 | 4.5-4.625" |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Country of Origin (Primary) | US |
| Emission Code | Legal US |
| Finish | Powdercoat |
| Fmvss Certification | N/A (See notes) |
| Front Lift Height | 5" |
| Front Lift Method | Knuckle & Drop Cross-Member |
| GTIN | 00810156360855 |
| Hazardous Material Code | N |
| Installation Difficulty | 4 out of 5 |
| Installation Time | 6-8 hrs |
| Life Cycle Status Code | Available to Order |
| Lift Type | Suspension |
| Material | 1/4" Steel |
| Max Tire Size | 37 x 12.5 |
| Max Tire Size 2 | 35 x 12.5 |
| Max Tire Size 3 | 35 x 12.5 |
| NAFTA Preference Criterion Code | B |
| Rear Lift Height | 4.5" |
| Rear Lift Method | Block Kit |
| Requires Metal Cutting | Yes |
| Requires Welding | No |
| SDR Required Flag | N |
| Wheel Size | 20 x 9 |
| Wheel Size 2 | 20 x 10 |
| Wheel Size 3 | 17 x 9 |
Zone Offroad Products ZONC43F Zone 5 Suspension Lift Kit
Product Information
- Brand: Zone Offroad Products
- Product Number: ZONC43F
This item is a package with the following components: ZONC2459, ZONC2501, ZONC2500, ZONC2502, ZONC2503, ZONC2504, FOX98450614, FOX98450759
