TeraFlex Coil Spring Base Lift Kits raise your Jeep for more off-road ground clearance. These kits require additional components to correct suspension geometry - sold separately.
The TeraFlex 4" Coil Spring Base Lift Kit w/ Front Track Bar includes just the basic lift components only and doesn?t have the drivability of a full suspension system. Requires adjustable short or long Alpine (IR) Control Arms and/or Rear HD Forged Adjustable Track Bar to correct suspension geometry. We recommend Falcon Performance Shocks or TeraFlex 9550 VSS Twin-Tube Shocks. These are the only shock absorbers engineered to work with TeraFlex lift coil springs to improve both compression and rebound for optimal vehicle stability. 4.5" Coil Spring Base Lift Kits are offered with TeraFlex 9550 VSS Twin-Tube Shocks or without shock absorbers. Falcon Performance Shocks are available separately.
Application Summary:
| Year |
Make/Model |
| 2007-2017 |
Jeep Wrangler |
| 2018 |
Jeep Wrangler JK |
| Attributes |
| California Proposition 65 |
Yes |
| Country of Origin (Primary) |
CN |
| GTIN |
00843885020592 |
| Harmonized Tariff Code (Schedule B) |
8708807000 |
| Hazardous Material Code |
N |
| Included Parts |
4" Lift Coil Spring Kit (JK4 Front: # 1853402 & JK4 Rear: # 1854402), 0.5 in. Lift Coil Spring Spacers (Front x 2: 1953100 & Rear x 2: # 1954105), HD Forged Adjustable Track Bar - Front (0-6" Lift) (# 1753418), Rear Track Bar Axle Bracket Kit (3-6" Lift) (# 1954777), 2.75" Bump Stop Extension Kit - Front Upper (# 1953800), 1.25" SpeedBump Bump Stop Strike Pad Kit - Front Lower (# 1467125), 2" Bump Stop Extension Kit - Rear Upper (4-6" Lift) (# 1954802), 0.75" SpeedBump Bump Stop Strike Pad Kit - Rear Lower (# 1954600), 10" Front Sway Bar Quick Disconnect Kit (3-4" Lift) (# 1753000), 12.25" Rear Sway Bar Link Kit (3-4" Lift) (# 1754500), 26" Stainless-Steel Brake Line Kit - Front (# 4353310), 30" Stainless-Steel Brake Line Kit - Rear (# 4350310), All necessary hardware, And more, 9550 VSS Twin-Tube Shock Kit (3-4" Lift) (# 1545200) |
| Install Time |
5 Hours |
| Life Cycle Status Code |
Available to Order |
| Material |
Steel, polyurethane, rubber |
| NAFTA Preference Criterion Code |
B |
| SDR Required Flag |
N |
