Suspension Lift Kit; 4.5 in.; w/Vertex Shocks; Lifted Coil Springs; Extended Sway-Bar Links; Brackets; Stainless Steel Brake Lines; Bumpstop Spacers; Hardware;
This suspension features luxury ride coil springs matching OE coils rates that are specifically designed for diesel motors. A heavy duty track bar relocation bracket properly centers the axle and matches the steering angles created by the supplied drop pitman arm while the radius arm drop brackets maintain the Super Duty's O.E. caster angles. A steering stabilizer relocation bracket maintains proper steering control but a RC problem solver single unit is recommended with larger tires and a RC dual stabilizer is required when running 37in tires.
- Easy Bolt-On Installation
- Increased Ground Clearance
- Levels The Front With The Rear Of The Vehicle
- Fabricated Blocks Offer A Longer Lifespan Than Cast Blocks
- Specially Designed Anti-Axle Wrap Rear Blocks
- Radius Arm Drop Brackets Allow For Properly Set Caster
- Includes Application Valved N3 Series Shock Absorbers
Information:
If vehicle is equipped with rear overload leafs, they will need to be removed
Application Summary:
| Year |
Make/Model |
| 2008-2010 |
Ford F-250 Super Duty |
| 2008-2010 |
Ford F-350 Super Duty |
| Attributes |
| California Proposition 65 |
No |
| Country of Origin (Primary) |
TH |
| Front Components |
Lifted coil springs, Radius arm drop brackets, Extended sway-bar links, Track bar drop bracket, Pitman arm, Stainless steel braided brake lines, Bumpstop spacers, Hardware |
| Front Kit Componenets |
Lifted coil springs, Radius arm drop brackets, Extended sway-bar links, Track bar drop bracket, Pitman arm, Stainless steel braided brake lines, Bumpstop spacers, Hardware |
| Front Kit Components |
Lifted coil springs, Radius arm drop brackets, Extended sway-bar links, Track bar drop bracket, Pitman arm, Stainless steel braided brake lines, Bumpstop spacers, Hardware |
| GTIN |
00843030153045 |
| Harmonized Tariff Code (Schedule B) |
8708809900 |
| Hazardous Material Code |
N |
| Install Time |
6-8 hours |
| Life Cycle Status Code |
Available to Order |
| Lift/Drop Height |
4.5 in. |
| NAFTA Preference Criterion Code |
D |
| Rear Components |
Fabricated anti-wrap lift blocks, Carrier bearing drop bracket, U-bolts, Hardware |
| Rear Kit Components |
Fabricated anti-wrap lift blocks, Carrier bearing drop bracket, U-bolts, Hardware |
| SDR Required Flag |
N |
| Tire, Wheel, and Offset Info |
35x12.50R17:17x9:8x170:-12:-; 35x12.50R18:18x9:8x170:-12:-; 35x12.50R20:20x9:8x170:-12:- |
