2019-2022 RAM Rebel/TRX Front Bumper Flush LED Light Bar System
This new auxiliary light design from ORACLE Lighting incorporates both TIR (Total Internal Reflection) and LED Reflector Facing Technology to create a high-quality light output with a precision beam pattern. By combining both optic technologies this light provides an average 30 degree beam pattern and projects up to nearly 500M overall distance. The integrated LED marker lights feature both White and Amber LEDs which can be utilized for parking lights, DRL, and/or Turn Signals.
- Housing: Polycarbonate
- Lens: Optically Clear Lexan
- Watts: 100W (20x 5W LED)
Information:
3000K - Yellow Lens
Application Summary:
| Year |
Make/Model |
| 2019-2024 |
Ram 1500 |
| Attributes |
| AMP Draw |
7.5A at 12VDC |
| Add-On |
N/A |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Country of Origin (Primary) |
US |
| GTIN |
00810030395591 |
| Harmonized Tariff Code (Schedule B) |
8512200000 |
| Hazardous Material Code |
N |
| Housing |
Polycarbonate |
| Kelvin Temperature |
5500K |
| LED |
Osram CRDP LED Chip |
| LED Life |
50,000+ Hours |
| Lens |
Optically Clear Lexan |
| Life Cycle Status Code |
Available to Order |
| Lumen Output |
12000 |
| NAFTA Preference Criterion Code |
B |
| Optics |
Mixed Spot/ Flood |
| SDR Required Flag |
N |
| Voltage |
9V-36V DC |
| Warranty Time |
1 |
| Waterproof Rating |
IP69K |
| Watts |
100W (20x 5W LED) |
