modular design and patented Gravity LED optic system.
Inspired by endurance racing and tested by KC athletes worldwide, the Pro6 is set to break all performance barriers while providing the most durable, reliable, and scalable LED light bar design available today.RAW Lumens: 2,200 lmRAW Lumens: 2,200 lmRaw Lumens: 2,300 lmRaw Lumens: 2,300 lm Patented Gravity(R) LED G6 optical inserts provide exceptional efficiency and light output. 20W, G6 optics are available in Spot, Driving, and Wide-40 patterns. The patented Infinity Ring(TM) system provides a race-proven, adjustable linking system featuring expandable widths, modular beam shape, and a radius or straight setting between each ring. The Pro6 LED light bar uses high-strength aluminum end mounts designed specifically as a Yamaha YXZ1000Rspecific system including overhead roof mounts and all necessary hardware.
- Combo Wide-40 and Driving Beam Pattern
- Deluxe Plug-N-Play Wiring Harness W/ 30 amp LED Switch
- Extremely high output with very low amperage draw
- Powered by Gravity(R) LED G6 optical inserts efficient, powerful, patented
Information:
FEATURES-Powered by Gravity LED G6 optical inserts ? efficient; powerful; patented-Patent-pending Infinity Ring system enables the conversion of the Pro6 from straight to radius format in seconds (Patent-pending Application 14/704;736)-Signature KC modular design is expandable to different widths-Extremely high output with very low amperage draw-Combo Wide-40 and Driving Beam PatternLIGHT PERFORMANCE-Raw Lumens: 14;712 lm-Lux @ 10 Meters: 7;820 lx-Candela: 782;000 cd-Beam Distance (Meters): 1;769mSPECIFICATIONS-Wattage: 120W-Amp Draw: 9.78A-Voltage: 9-32V-Dimensions: H-6.06in. x D-3.33in. x W-39.125in.PARTS INCLUDED-(1) 39in. Pro6 6-Light LED Light Bar-Deluxe Plug-N-Play Wiring Harness W/30 amp LED SwitchPERFORMANCE Gravity LED OPTICSPatented Gravity LED G6 optical inserts provide exceptional efficiency and light output. 20W; G6 optics are available in Spot; Driving and Wide-40 patterns.INFINITY Ring SYSTEMThe Infinity Ring system provides a race-proven; adjustable linking system featuring expandable widths; modular beam shape and a radius or straight setting between each ring.YAMAHA END MOUNT SYSTEMThe Pro6 LED light bar uses high-strength aluminum end mounts designed specifically as a Yamaha YXZ1000R-specific system including overhead roof mounts and all necessary hardware.RACE PROVEN STRENGTH/DURABILITYInspired by endurance racing and tested by KC athletes worldwide; the Pro6 is set to break all performance barriers while providing the most durable; reliable and scalable light bar design available today
Application Summary:
| Year |
Make/Model |
| 2016-2019 |
Yamaha YXZ1000R |
| 2016-2019 |
Yamaha YXZ1000R SE |
| 2017-2019 |
Yamaha YXZ1000R SS |
| 2017-2019 |
Yamaha YXZ1000R SS SE |
| Attributes |
| AMP Draw |
9.78A |
| Add-On |
N/A |
| Beam Distance (Meters) |
1,435m |
| Beam Pattern |
Combo |
| California Proposition 65 |
No |
| Candela |
515,000 cd |
| Color Temperature |
5000K |
| Country of Origin (Primary) |
TW |
| GTIN |
00084709913106 |
| Harmonized Tariff Code (Schedule B) |
8512202000 |
| Hazardous Material Code |
N |
| IP Rating |
IP68 |
| LUX |
5150 |
| Life Cycle Status Code |
Available to Order |
| Light Temp |
5000K |
| Lumens |
14712 |
| Lux at 10 Meters |
5,150 lx |
| Lux at 10 Meters |
5,150 lx |
| NAFTA Preference Criterion Code |
B |
| Overall Length |
39.000 in. |
| Overall Length (in.) |
39.000 in. |
| Parts Included |
(1) 39 in Pro6 6Light LED Light Bar, (6) Light Covers Black with Yellow KC Logo, Deluxe Plug-n-Play Wiring Harness W/ LED Switch |
| Product Dimensions |
H 6.06 in x D 3.33 in x W 39.125 in |
| Raw Lumens |
13,800 lm |
| SDR Required Flag |
N |
| Voltage |
9-32V |
| Warranty Note |
This item has exceptions to the warranty period. Please visit kchilites.com/warranty for details and exceptions. |
| Warranty Time |
23 |
| Wattage |
120W |
