This 5800 Series Rotating Halogen Beacon (4.9 amps, 12V) is a low profile, red colored beacon with a 55W halogen bulb & a twist-on lens that secures with a locking screw. It measures 8.2"H x 5.3"W & has a DIN Pole mount.

---

Available in a wide range of base mountings and two height profiles, these rotating beacons produce SAE Class I light output. The 5800 series incorporates a smooth and quiet belt drive module with stainless steel bearings that provides long life and reliable service. Reflectors incorporate a free-form optical design that maximizes light output and beam spread.

• Low profile; 12V; Red Color; Rotating Flash Pattern; 8.2"H x 5.3"W; 4.9 amps; 195 FPM; DIN Pole Mount; Approval Ratings: SAE J845 Class I, CE, R10, R65; Twist-on lens secures with a locking screw; 55-watt halogen bulb;

---

Information:

Rotating Beacon; Low profile; 12V; Red Color; Rotating Flash Pattern; 8.2" Height x 5.3" Width; 4.9 amps; 195 FPM; DIN Pole Mount; Approval Ratings: SAE J845 Class I, CE, R10, R65; Economical style beacon available in several mounting styles; DIN models designed to fit DIN #72591; Twist-on lens secures with a locking screw; 55-watt halogen bulb; Temperature Range: -22°F to +122°F (-30°C to +50°C); Warranty: Rotator = 1 year / Bulb = 3 month; Parts & Accessories: PN: R5812BH Bulb, PN: R5810LA Amber Lens, PN: R5840CA Amber High Profile Lens.
