2-1/16in. TRANSMISSION TEMPERATURE; 100-300 deg.F; SPEK-PRO; WHITE/BLACK
Transmission fluid temperature is the single biggest contributing factor to the lifespan of your automatic transmission. Having an accurate, realtime measurement allows you to know when to downshift or when to take your foot out of it. Whether you're towing or simply trying to harness the power of a built or boosted motor, AutoMeter's Digital Stepper Motor Trans Temp Gauge will give you the most accurate possible measurement for the exact temp of your trans fluid. AutoMeter's most advanced 1/8 NPT temperature transducer is included as well as a direct plug in wiring harness for ease of installation. An optional trans cooler line manifold is available for another easy installation option.
Transmission fluid temperature is the single biggest contributing factor to the lifespan of your automatic transmission. Having an accurate, realtime measurement allows you to know when to downshift or when to take your foot out of it. Whether you're towing or simply trying to harness the power of a built or boosted motor, AutoMeter's Digital Stepper Motor Trans Temp Gauge will give you the most accurate possible measurement for the exact temp of your trans fluid. AutoMeter's most advanced 1/8 NPT temperature transducer is included as well as a direct plug in wiring harness for ease of installation. An optional trans cooler line manifold is available for another easy installation option.
- 7 Color User Selectable
- Independent Dimming For Dial And Pointer
- Provides The Largest Viewable Dial Programmable
- Precision 280 Brushless Stepper Motor
- High And Low Warning Settings
- Thread On Bracket/Plug In Harness Included
- Features A Peak Recall Function/Enables User To Review
- Highest Reading Will Be Stored By Gauge Until It Is Cleared
Information:
7 Color User Selectable; Independent Dimming For Dial And Pointer; Provides The Largest Viewable Dial Programmable; Precision 280 Brushless Stepper Motor; High And Low Warning Settings; Thread On Bracket And Plug In Harness Included; Features A Peak Recall Function/Enables User To Review; Highest Reading Will Be Stored By Gauge Until It Is Cleared| Attributes | |
| ASIN | B00B81SPN4 |
| Add-On Part | N/A |
| BEZEL COLOR | Black |
| Bezel Style | Round Shoulder |
| California Proposition 65 | WARNING: Cancer - www.P65Warnings.ca.gov |
| Country of Origin (Primary) | US |
| Dial (Face Color) | White |
| Emission Code | Legal US |
| Face Color | White |
| Fitting Type | 0.500 in. NPT |
| Fittings Included | Yes |
| GTIN | 00046074153440 |
| Gauge Size | 2.0625 in., 52.4mm |
| Gauge Type | Transmission Temperature |
| Harmonized Tariff Code (Schedule B) | 9025198080 |
| Hazardous Material Code | N |
| Hole Size | 2.050 in., 52.1mm |
| Lens | Domed Clear |
| Life Cycle Status Code | Available to Order |
| Lighting Color | 7 User Selectable Colors |
| Lighting Type | LED |
| Movement Type | Electric Digital Stepper Motor |
| NAFTA Preference Criterion Code | B |
| Outer Bezel Diameter | 2.360 in. |
| Pointer Color | Fluorescent Red |
| SDR Required Flag | N |
| Warranty Time | 12 |
AutoMeter Products P34212 Trans Temperature Gauge 2 1/16", 300Γö¼ΓòæF, Stepper Motor White
Product Information
- Brand: AutoMeter Products
- Product Number: P34212
