2-1/16in. BOOST CONTROLLER; 30 IN HG/30 PSI; SPORT-COMP
Offering an unparalleled feature set, the AutoMeter Boost Controller redefines what a boost controller should be. In addition to the standard hi/lo mode, boost by RPM and boost by gear give you absolute control of your power delivery. Initial setup is is incredibly simple using an intuitive menu and a revolutionary gear capture process. Configurable warnings with peak recall and boost shutdown are standard safety features designed to protect your engine. A scalable display range allows you to tailor resolution to show only the needed range for your application. AutoMeter's Pro Control output system is equipped to allow electric devices to be controlled at a user defined boost pressure (such as water/meth injection, nitrous, etc.) as well as Pro-Control input to default to waste gate spring pressure should the need arise. Display pressure in PSI, BAR, or kPa and easily data log and display with or without realtime barometric compensation. A direct plug wiring harness is included for ease of installation.
  • Incl. 6 ft. Wiring Harness
  • Configurable Data Logger Output For Easy Integration
  • No Need For External Modules
  • Programmable Boost By Gear
  • Boost By RPM
  • MAP Sensor
  • Boost Control Valve
  • Programmable High Boost Warning/Shutdown Modes
  • Peak Boost Recall
  • Ideal For Single Or Twin Turbocharged Applications
  • Not For Diesel Application Or Wastegate-less Setups

Information:

Incl. 6 ft. Wiring Harness; MAP Sensor; Boost Control Valve; Programmable High Boost Warning And Shutdown Modes; Peak Boost Recall; Ideal For Single Or Twin Turbocharged Applications; Not For Diesel Application Or Wastegate-less Setups; Configurable Data Logger Output For Easy Integration; No Need For External Modules; Programmable Boost By Gear; Boost By RPM
Attributes
ASIN B00O0MXQOG
Add-On Part N/A
BEZEL COLOR Brushed Aluminum
Bezel Style Super Bezel
Boost 0 to 30 PSI
California Proposition 65 WARNING: Cancer - www.P65Warnings.ca.gov
Country of Origin (Primary) US
Dial (Face Color) Black
Emission Code Off Road
Face Color Black
Face Size 2.0625 / 2 1/16
GTIN 00046074033810
Gauge Size 2.0625 in., 52.4mm
Gauge Type Boost Controller
Harmonized Tariff Code (Schedule B) 9026200000
Hazardous Material Code N
Hole Size 0.0625 in., 52.4mm
Lens Flat Clear
Life Cycle Status Code Available to Order
Lighting Color Red LCD/Red Yellow Green Segments
Lighting Type Digital LED
Movement Type Digital
NAFTA Preference Criterion Code B
Outer Bezel Diameter 2.225 in.
Pointer Color N/A
SDR Required Flag N
Size 2.3125 in.
Size (in.) 2-1/16
Warranty Time 12
