Large Bore-HD 4 IN DPF-Back Stainless Steel Exhaust System w/Black Tip Nissan Titan XD 16-19 V8-5.0L (td)
aFe LARGE BORE HD exhaust systems are constructed from mandrel-bent stainless steel tubing for maximum flow. Smooth transition bends allow for low turbulence, increasing horsepower and torque, while decreasing EGT. The 2-piece design and bayonet style hangers provide stability and for an easy installation. Finishing off the exhaust is a black, stainless steel slash cut tip with intercooling vents designed to reduce exhaust gas temperatures at the tailpipe. A unique stainless steel laser-cut aFe Power logo plate is riveted on for an aggressive style.
- ATLAS Systems Have A 2-Piece Design To Ensure Proper Fitment
- ATLAS System Use Factory Mounting Location For Easy Installation
- Comes w/OE Style Bayonet Hangers For A Secure Fit
- Includes High Quality Band Clamps For An Improved Seal
- Made From Mandrel Bent Aluminized Steel Tubing For Maximum Flow
- Smooth Bends Allow For Low Increased Horsepower And Torque
- Fits Crew Cab/Standard Bed 151.6 in Wheelbase/6-6 Ft. Bed
Application Summary:
| Year |
Make/Model |
| 2016-2019 |
Nissan TITAN XD |
| Attributes |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Clamps Included |
Yes |
| Country of Origin (Primary) |
US |
| Exhaust Tip Diameter |
5 |
| Exhaust Tip Finish |
Black Powder Coat |
| Exhaust Tip Material |
409 Stainless Steel |
| Exhaust Tip Quantity |
1 |
| Exhaust Type |
DPF-Back |
| Exit Position |
Rear Side |
| Exit Style |
Turn Out |
| Finish |
Natural |
| GTIN |
00802959600276 |
| Grade Type |
Performance |
| Hangers Included |
Yes |
| Harmonized Tariff Code (Schedule B) |
8708925000 |
| Hazardous Material Code |
N |
| Inlet Inside Diameter |
4 |
| Inlet Inside Diameter (in.) |
4 |
| Inlet Size (in.) |
4 |
| Inlet Type |
Sleeve |
| Life Cycle Status Code |
Available to Order |
| Material |
409 Stainless Steel |
| Muffler Quantity |
None |
| NAFTA Preference Criterion Code |
B |
| Outlet Outside Diameter |
4 |
| Outlet Outside Diameter (in.) |
4 |
| Outlet Size (in.) |
4 |
| Pipe Material |
409 Stainless Steel |
| SDR Required Flag |
N |
| Tail Pipe Material |
Stainless Steel |
| Tip Diameter |
5.000 in. |
| Tip Shape |
Round |
| Tip Size |
5 |
| Tubing Diameter |
4 |
| Warranty Time |
2 |
